Material Overview

Nickel 200 material profile

A concise grade introduction for buyers who need to confirm composition, properties, standards, available forms and suitable applications before sending an inquiry.

Engineering profile

Nickel 200 is a commercially pure wrought nickel offering excellent resistance to caustic alkalis, good performance in many reducing chemicals and useful thermal, electrical and magnetic properties. Its combination of ductility, toughness and fabrication capability makes it suitable for chemical processing, food-production equipment, electrical components, aerospace parts and alkaline handling systems. For prolonged service above approximately 315 °C, the low-carbon Nickel 201 grade is generally preferred to reduce the risk of graphitization.

Technical data on this page is for material selection reference. Final acceptance values should be confirmed by the purchase standard, heat treatment condition, product form, size and material test certificate.

Chemical Composition

Nickel 200 composition range

The following table shows common limiting composition values for Alloy 625 / UNS N06625. Actual product chemistry is reported by heat on the material test certificate.

Element	Symbol	Typical Requirement	Role in Nickel 200
Nickel + Cobalt	Ni + Co	99.0 min	Forms the commercially pure nickel base and provides corrosion resistance, ductility and thermal stability.
Carbon	C	0.15 max	Contributes to strength but limits prolonged high-temperature service because of possible graphitization.
Iron	Fe	0.40 max	Controlled residual element that can influence strength and corrosion behavior.
Manganese	Mn	0.35 max	Controlled minor element and deoxidizer.
Silicon	Si	0.35 max	Controlled residual element and deoxidizer.
Copper	Cu	0.25 max	Controlled residual element.
Sulfur	S	0.010 max	Restricted impurity for improved ductility, welding and hot workability.

Physical Properties

Key physical and thermal data

These values help customers compare density, thermal behavior, magnetic response and conductivity during early material selection.

Property	Metric Value	Imperial / Notes	Condition
Density	8.89 g/cm3	0.321 lb/in3	Room temperature
Melting Range	1435-1446 °C	2615-2635 °F	Typical range
Specific Heat	Approx. 456 J/kg·°C	Approx. 0.109 Btu/lb·°F	Approx. 20 °C
Thermal Conductivity	Approx. 79.3 W/m·°C	Approx. 550 Btu·in/ft2·h·°F	Approx. 20 °C
Electrical Resistivity	Approx. 8.5 µΩ·cm	Approx. 51 ohm-cmil/ft	Approx. 20 °C
Modulus of Elasticity	Approx. 207 GPa	Approx. 30.0 x 10³ ksi	Annealed, room temperature
Mean Thermal Expansion	Approx. 13.3 µm/m·°C	Approx. 7.4 µin/in·°F	20-100 °C
Magnetic Behavior	Ferromagnetic	Permeability depends on condition and field strength	Below the Curie temperature

Mechanical Properties

Room-temperature mechanical properties

Mechanical properties vary with product form, size, processing route and heat treatment. The table below summarizes commonly referenced nominal values for material selection.

Product Form / Condition	Tensile Strength	Yield Strength, 0.2%	Elongation	Hardness
Plate, sheet and strip – annealed	380 MPa min	105 MPa min	40% min	Approx. 45-100 HB
Rod and bar – annealed	380 MPa min	105 MPa min	40% min	Approx. 45-100 HB
Rod and bar – cold drawn	485-690 MPa	350-620 MPa	15-30%	Approx. 120-200 HB
Seamless pipe and tube – annealed	380 MPa min	105 MPa min	40% min	By specification
Wire – annealed	380-550 MPa	105-250 MPa	30-45%	By size and condition
Forgings – annealed	380 MPa min	105 MPa min	30% min	By specification

For pressure equipment, aerospace parts or project-specific acceptance, use the minimum requirements in the specified ASTM, ASME, AMS, EN or customer drawing rather than nominal values.

Standards & Specifications

Common Nickel 200 standards by product form

YSN128 can quote Alloy 625 products according to ASTM, ASME, AMS, EN, DIN, ISO or customer drawing requirements. Certificate scope can be matched to the purchase order.

Product Form	Common Standards	Typical Supply Item	Certificate / Inspection
Plate, Sheet, Strip	ASTM B162 / ASME SB162	Hot rolled plate, cold rolled sheet, strip and cut blanks	EN10204 3.1, chemical analysis and mechanical testing
Rod and Bar	ASTM B160 / ASME SB160	Round bar, rod, cold-drawn bar and machined stock	MTC, PMI, tensile testing and dimensional inspection
Seamless Pipe & Tube	ASTM B161 / ASME SB161	Seamless pipe, process tube and pressure-system tube	Hydrostatic test, eddy-current test and MTC
Heat Exchanger Tube	ASTM B163 / ASME SB163	Seamless condenser tube, heat-exchanger tube and evaporator tube	Eddy-current test, hydrostatic test and dimensional inspection
Welded Pipe	ASTM B730 / ASME SB730	Longitudinally welded process pipe and fabricated piping	Radiographic or ultrasonic inspection, hydrotest and MTC
Forgings and Flanges	ASTM B564 / ASME SB564	Rings, discs, blocks, flanges and custom forgings	Heat-treatment record, ultrasonic testing, PMI and MTC
Fittings	ASTM B366 / ASME SB366	Elbows, tees, reducers, caps and drawing-based fittings	PMI, dimensional inspection, penetrant testing and MTC
Welding Products	AWS A5.14 ERNi-1, AWS A5.11 ENi-1	Nickel welding wire, bare electrodes and covered electrodes	Chemical analysis, mill certificate and dimensional inspection

Available Product Forms

Nickel 200 supply range

Review available product forms, size ranges, standards and delivery options for this alloy.

Form	Common Size Range	Delivery Condition	Typical Applications	Page Link
Pipe & Tube	OD 6-762 mm, wall thickness or schedule to specification	Seamless or welded, annealed, pickled or bright annealed	Caustic soda systems, chemical piping, evaporators and heat exchangers	View Pipe & Tube
Round Bar	Diameter 3-500 mm, custom cut lengths available	Hot rolled, forged, annealed, cold drawn, peeled or polished	Valve parts, anodes, electrical components and machined chemical equipment	View Round Bar
Sheet & Plate	Thickness 0.5-150 mm, custom widths and lengths	Hot rolled, cold rolled, annealed, pickled or polished	Chemical vessels, food equipment, alkaline tanks and fabricated components	View Sheet & Plate
Strip & Foil	Thickness 0.02-5 mm, precision slit widths available	Cold rolled, annealed, bright finished or coil supplied	Battery components, electrical contacts, diaphragms and precision formed parts	View Strip & Foil
Wire	Diameter 0.1-20 mm, coil, spool or straight-length supply	Cold drawn, annealed, bright or pickled	Electrical leads, wire mesh, heating applications and welding-product manufacture	View Wire
Fasteners	Standard and custom bolts, nuts, screws, studs and washers	Annealed, cold worked, machined, rolled thread or custom finished	Caustic processing, food equipment, chemical plants and electrical systems	View Fasteners
Fittings	ASME, ANSI, EN and custom drawing dimensions	Seamless, welded, formed or machined, annealed	Alkaline piping, food-processing lines and chemical process systems	View Fittings
Flanges	ASME B16.5, ASME B16.47, EN and custom large-diameter designs	Forged, annealed, machined and inspected	Chemical piping, pressure vessels, evaporators and caustic handling systems	View Flanges
Forgings	Rings, discs, blocks and shafts up to 2000 mm or drawing requirements	Open-die or closed-die forged, annealed and machined	Pressure parts, chemical equipment, electrical components and custom hardware	View Forgings
Welding Wire	Diameter 0.8-4.0 mm, spool, coil or straight length	Precision drawn, clean bright finish and controlled chemistry	Joining Nickel 200, commercially pure nickel fabrication and repair welding	View Welding Wire

Material Selection Guide

When to consider Nickel 200

This guide helps buyers connect service conditions with the typical advantage of Alloy 625. Final selection should consider medium concentration, temperature, pressure, fabrication, availability and budget.

Service Requirement	Why Nickel 200 Helps	Common Product Form	Buyer Note
Caustic alkali processing	Commercially pure nickel provides excellent resistance to many caustic soda and alkaline solutions.	Plate, pipe, tube, fittings and fabricated vessels	Confirm concentration, temperature, aeration and possible contaminants.
Reducing chemical environments	The high nickel content provides useful resistance to many reducing chemicals and neutral salts.	Pipe, tube, plate, fittings and valve components	Review the complete process chemistry because oxidizing contaminants can change corrosion behavior.
Thermal and electrical components	Nickel 200 offers relatively high thermal and electrical conductivity compared with most nickel alloys.	Strip, foil, wire, bar and machined components	Specify conductivity, temper, dimensions and surface-finish requirements.
Food-processing equipment	The alloy combines corrosion resistance, ductility and cleanable surfaces in selected food-production environments.	Sheet, plate, tube, fittings and fabricated vessels	Confirm product-contact, cleaning and surface-finish requirements.
Fabrication requiring high ductility	Annealed Nickel 200 has good formability and can be rolled, drawn, spun and welded.	Sheet, strip, tube, wire and formed components	Specify annealed temper, forming severity and final dimensional tolerances.
Continuous service below approximately 315 °C	Nickel 200 provides good mechanical and corrosion performance when graphitization is not a concern.	Plate, sheet, pipe, tube, bar and fittings	For prolonged exposure above approximately 315 °C, consider low-carbon Nickel 201.

Why Choose Us

Supply and quality support for Nickel 200

For ranking traffic, buyers need more than a data sheet. This section gives clear trust signals for procurement, engineering and quality teams.

STASTM / ASME / AMS / EN

Quotation can be matched to project standards and product form specifications.

MTEN10204 3.1 MTC

Heat number, chemistry, mechanical properties and inspection records can be supplied.

QCPMI & Inspection

PMI, UT, dimensional inspection, visual inspection and packing check are available.

CSCustom Size

Cutting, machining allowance, rough machining and drawing-based supply can be arranged.

EPExport Packing

Wooden case, bundle, waterproof protection and international shipping documents.

RFFast Technical Reply

Send grade, size, standard, quantity and destination for a practical quotation route.

Related Nickel Alloys

Compare nearby grades and product forms

Explore related grades and product forms for comparison.

Nickel Nickel 201

Nickel 201 is a low-carbon, commercially pure wrought nickel combining excellent resistance to caustic alkalis and many reducing chemicals with good thermal and electrical conductivity....

FAQ

Nickel 200 questions from buyers

Find practical answers about procurement, standards, fabrication and industrial applications.

Nickel 200 is used for caustic soda equipment, chemical processing systems, food-production machinery, electrical components, battery parts, evaporators and fabricated equipment requiring commercially pure nickel.

Yes. UNS N02200 is the standardized UNS designation for Nickel 200. The material may also be identified as Alloy 200, W.Nr. 2.4066 or Ni 99.2.

Nickel 200 permits a higher carbon content and generally has slightly higher minimum annealed strength. Nickel 201 limits carbon to 0.02%, reducing the risk of graphitization during prolonged exposure above approximately 315 °C.

YSN128 can quote plate, sheet, strip, foil, round bar, rod, wire, seamless pipe, tube, forgings, flanges, fittings, fasteners and welding wire. Cutting, polishing, machining and drawing-based supply can also be discussed.

Common specifications include ASTM B162 for plate and sheet, ASTM B160 for rod and bar, ASTM B161 for seamless pipe and tube, ASTM B163 for heat-exchanger tube, ASTM B564 for forgings and ASTM B366 for fittings. Related ASME specifications are available for pressure equipment.

Yes. Nickel 200 can be welded using suitable gas-tungsten arc, gas-metal arc and shielded-metal arc procedures. Compatible filler metals such as ERNi-1 may be used, subject to the approved welding procedure and service conditions.

Nickel 200 can be used at moderate temperatures, but prolonged exposure above approximately 315 °C may cause graphitization and loss of ductility. Low-carbon Nickel 201 is generally preferred for continuous service above this temperature.

Please send the product form, dimensions, quantity, applicable ASTM or ASME standard, delivery condition, temper, surface finish, certificate requirements, destination and service temperature. Process chemistry should also be provided when material suitability must be reviewed.
