Home > Alloys > Hastelloy > Hastelloy C-2000

Nickel Alloy Grade Data Sheet

Hastelloy C-2000

Hastelloy C-2000 is a nickel-chromium-molybdenum alloy with a controlled copper addition developed for broad resistance to oxidizing and reducing chemicals. Its high chromium content improves performance in oxidizing media, molybdenum provides resistance to reducing acids and localized corrosion, and copper extends resistance in many sulfuric acid environments. Alloy C-2000 is commonly specified for chemical processing, acid production, pharmaceutical equipment, pickling systems, pollution control and process equipment exposed to changing or contaminated chemical streams.







Download Hastelloy C-2000 Datasheet Send Inquiry
Material Overview

Hastelloy C-2000 material profile

A concise grade introduction for buyers who need to confirm composition, properties, standards, available forms and suitable applications before sending an inquiry.

Engineering profile

Hastelloy C-2000 is a nickel-chromium-molybdenum alloy with a controlled copper addition developed for broad resistance to oxidizing and reducing chemicals. Its high chromium content improves performance in oxidizing media, molybdenum provides resistance to reducing acids and localized corrosion, and copper extends resistance in many sulfuric acid environments. Alloy C-2000 is commonly specified for chemical processing, acid production, pharmaceutical equipment, pickling systems, pollution control and process equipment exposed to changing or contaminated chemical streams.







Hastelloy C-2000

Technical data on this page is for material selection reference. Final acceptance values should be confirmed by the purchase standard, heat treatment condition, product form, size and material test certificate.

Chemical Composition

Hastelloy C-2000 composition range

The following table shows common limiting composition values for Alloy 625 / UNS N06625. Actual product chemistry is reported by heat on the material test certificate.

Element Symbol Typical Requirement Role in Alloy C-2000
Nickel Ni Balance Forms the corrosion-resistant alloy base and provides metallurgical stability.
Chromium Cr 22.0-24.0 Provides strong resistance to oxidizing chemicals and supports passive-film formation.
Molybdenum Mo 15.0-17.0 Improves resistance to reducing acids, pitting and crevice corrosion.
Copper Cu 1.30-1.90 Extends resistance in sulfuric acid and selected reducing chemical environments.
Iron Fe 3.0 max Controlled to preserve the intended nickel-chromium-molybdenum corrosion performance.
Cobalt Co 2.0 max Controlled residual and minor alloying element.
Manganese Mn 0.50 max Controlled minor element and deoxidizer.
Aluminum Al 0.50 max Controlled minor alloying and deoxidizing element.
Carbon C 0.010 max Restricted to minimize carbide precipitation and preserve weld-zone corrosion resistance.
Silicon Si 0.080 max Restricted to reduce formation of harmful intermetallic phases during welding.
Phosphorus P 0.025 max Controlled impurity for consistent fabrication and corrosion performance.
Sulfur S 0.010 max Restricted impurity for improved hot workability and weld quality.





Physical Properties

Key physical and thermal data

These values help customers compare density, thermal behavior, magnetic response and conductivity during early material selection.

Property Metric Value Imperial / Notes Condition
Density 8.50 g/cm3 0.307 lb/in3 Room temperature
Melting Range 1370-1410 °C 2498-2570 °F Typical range
Specific Heat Approx. 414 J/kg·°C Approx. 0.099 Btu/lb·°F Approx. 20 °C
Thermal Conductivity Approx. 9.1 W/m·°C Approx. 63 Btu·in/ft2·h·°F Approx. 20 °C
Electrical Resistivity Approx. 128 µΩ·cm Approx. 770 ohm-cmil/ft Approx. 20 °C
Modulus of Elasticity Approx. 205 GPa Approx. 29.7 x 103 ksi Solution annealed, room temperature
Mean Thermal Expansion Approx. 11.3 µm/m·°C Approx. 6.3 µin/in·°F 20-100 °C
Magnetic Permeability Approx. 1.001 Essentially non-magnetic Solution annealed, room temperature





Mechanical Properties

Room-temperature mechanical properties

Mechanical properties vary with product form, size, processing route and heat treatment. The table below summarizes commonly referenced nominal values for material selection.

Product Form / Condition Tensile Strength Yield Strength, 0.2% Elongation Hardness
Plate, sheet and strip – solution annealed 690 MPa min 310 MPa min 40% min By specification
Rod and bar – solution annealed 690 MPa min 310 MPa min 40% min By specification
Rod and bar – cold worked 825-1100 MPa 550-900 MPa 15-30% Condition dependent
Seamless pipe and tube – solution annealed 690 MPa min 310 MPa min 40% min By specification
Wire – annealed 690-900 MPa 310-500 MPa 30-45% By size and condition
Forgings and rings – solution annealed 690 MPa min 310 MPa min 30% min By specification





For pressure equipment, aerospace parts or project-specific acceptance, use the minimum requirements in the specified ASTM, ASME, AMS, EN or customer drawing rather than nominal values.

Standards & Specifications

Common Hastelloy C-2000 standards by product form

YSN128 can quote Alloy 625 products according to ASTM, ASME, AMS, EN, DIN, ISO or customer drawing requirements. Certificate scope can be matched to the purchase order.

Product Form Common Standards Typical Supply Item Certificate / Inspection
Plate, Sheet, Strip ASTM B575 / ASME SB575 Hot rolled plate, cold rolled sheet, strip and cut blanks EN10204 3.1, chemical analysis and mechanical testing
Rod and Bar ASTM B574 / ASME SB574 Round bar, rod, machined bar and cut lengths MTC, PMI, tensile testing and dimensional inspection
Seamless Pipe & Tube ASTM B622 / ASME SB622 Seamless pipe, process tube and heat-exchanger tube Hydrostatic test, eddy-current test and MTC
Welded Pipe ASTM B619 / ASME SB619 Longitudinally welded pipe and fabricated process piping Radiographic or ultrasonic inspection, hydrotest and MTC
Welded Tube ASTM B626 / ASME SB626 Welded process tube and heat-exchanger tube Eddy-current test, hydrostatic or pneumatic test and MTC
Forgings and Flanges ASTM B462 / ASME SB462 Rings, discs, blocks, flanges and custom forgings Heat-treatment record, ultrasonic testing, PMI and MTC
Fittings ASTM B366 / ASME SB366 Elbows, tees, reducers, caps and drawing-based fittings PMI, dimensional inspection, penetrant testing and MTC
Welding Products AWS A5.14 ERNiCrMo-17, AWS A5.11 ENiCrMo-17 Matching welding wire, bare electrodes and covered electrodes Chemical analysis, mill certificate and dimensional inspection





Available Product Forms

Hastelloy C-2000 supply range

Review available product forms, size ranges, standards and delivery options for this alloy.

Form Common Size Range Delivery Condition Typical Applications Page Link
Pipe & Tube OD 6-762 mm, wall thickness or schedule to specification Seamless or welded, solution annealed, pickled or bright annealed Acid piping, chemical reactors, heat exchangers and pharmaceutical systems View Pipe & Tube
Round Bar Diameter 3-500 mm, custom cut lengths available Hot rolled, forged, solution annealed, peeled or polished Pump shafts, valve parts, fasteners and machined corrosion-resistant components View Round Bar
Sheet & Plate Thickness 0.5-150 mm, custom widths and lengths Hot rolled, cold rolled, solution annealed, pickled or polished Process vessels, reactors, acid tanks, scrubbers and fabricated equipment View Sheet & Plate
Strip & Foil Thickness 0.02-5 mm, precision slit widths available Cold rolled, solution annealed, bright finished or coil supplied Corrosion-resistant seals, liners, diaphragms and precision formed parts View Strip & Foil
Wire Diameter 0.1-20 mm, coil, spool or straight-length supply Cold drawn, solution annealed, bright or pickled Wire mesh, demister pads, springs and welding-product manufacture View Wire
Fasteners Standard and custom bolts, nuts, screws, studs and washers Solution annealed, machined, rolled thread or custom finished Chemical plants, acid equipment, pharmaceutical systems and scrubbers View Fasteners
Fittings ASME, ANSI, EN and custom drawing dimensions Seamless, welded, formed or machined, solution annealed Sulfuric acid piping, mixed-acid systems and chemical process lines View Fittings
Flanges ASME B16.5, ASME B16.47, EN and custom large-diameter designs Forged, solution annealed, machined and inspected Severe chemical piping, pressure vessels and pollution-control systems View Flanges
Forgings Rings, discs, blocks and shafts up to 2000 mm or drawing requirements Open-die or closed-die forged, solution annealed and machined Pump components, valve bodies, pressure parts and custom chemical equipment View Forgings
Welding Wire Diameter 0.8-4.0 mm, spool, coil or straight length Precision drawn, clean bright finish and controlled chemistry Joining Alloy C-2000, dissimilar-metal welding and corrosion-resistant overlay View Welding Wire





Material Selection Guide

When to consider Hastelloy C-2000

This guide helps buyers connect service conditions with the typical advantage of Alloy 625. Final selection should consider medium concentration, temperature, pressure, fabrication, availability and budget.

Service Requirement Why Alloy C-2000 Helps Common Product Form Buyer Note
Sulfuric acid service The copper addition extends resistance across many sulfuric acid concentrations and temperatures. Plate, pipe, tube, fittings and process vessels Specify concentration, temperature, aeration and contaminants.
Hydrochloric acid environments High nickel and molybdenum contents provide strong resistance to many reducing acid conditions. Pipe, tube, plate, fittings and heat exchangers Confirm acid concentration, temperature and oxidizing impurities.
Changing oxidizing and reducing media Chromium supports oxidizing resistance while molybdenum and copper improve performance in reducing conditions. Plate, pipe, tube, fittings and fabricated assemblies Review normal operation, cleaning, start-up and shutdown chemistry.
Pitting and crevice corrosion High molybdenum content provides strong resistance to localized corrosion in chloride-bearing media. Pipe, tube, sheet, plate, fittings and fasteners Check chloride concentration, temperature, deposits and crevice geometry.
Fine-chemical and pharmaceutical equipment Broad corrosion resistance supports processes involving multiple chemicals and cleaning media. Sheet, plate, tube, fittings and process vessels Specify surface finish, cleaning procedure and product-contact requirements.
Welded corrosion-resistant equipment Low carbon and silicon contents help preserve corrosion performance in welded structures. Plate, sheet, pipe, tube and welding wire Control cleanliness, heat input, interpass temperature and final inspection.





Why Choose Us

Supply and quality support for Hastelloy C-2000

For ranking traffic, buyers need more than a data sheet. This section gives clear trust signals for procurement, engineering and quality teams.

STASTM / ASME / AMS / EN

Quotation can be matched to project standards and product form specifications.

MTEN10204 3.1 MTC

Heat number, chemistry, mechanical properties and inspection records can be supplied.

QCPMI & Inspection

PMI, UT, dimensional inspection, visual inspection and packing check are available.

CSCustom Size

Cutting, machining allowance, rough machining and drawing-based supply can be arranged.

EPExport Packing

Wooden case, bundle, waterproof protection and international shipping documents.

RFFast Technical Reply

Send grade, size, standard, quantity and destination for a practical quotation route.

Related Nickel Alloys

Compare nearby grades and product forms

Explore related grades and product forms for comparison.

FAQ

Hastelloy C-2000 questions from buyers

Find practical answers about procurement, standards, fabrication and industrial applications.

Hastelloy C-2000 is used for sulfuric and hydrochloric acid processing, chemical reactors, pharmaceutical equipment, pickling systems, heat exchangers, pollution control and equipment exposed to variable process chemicals.

Yes. UNS N06200 is the standardized UNS designation for Hastelloy C-2000. The alloy may also be identified as Alloy C-2000, Nickel Alloy C-2000, W.Nr. 2.4675 or NiCr23Mo16Cu.

The controlled copper addition improves resistance to sulfuric acid and selected reducing environments. It complements the chromium used for oxidizing resistance and the molybdenum used for reducing acids and localized corrosion.

YSN128 can quote plate, sheet, strip, round bar, rod, wire, seamless pipe, welded pipe, tube, forgings, flanges, fittings, fasteners and welding wire. Cutting, forming, machining and drawing-based production can also be discussed.

Common specifications include ASTM B575 for plate and sheet, ASTM B574 for rod and bar, ASTM B622 for seamless pipe and tube, ASTM B619 for welded pipe, ASTM B626 for welded tube, ASTM B462 for forgings and ASTM B366 for fittings.

Yes. Alloy C-2000 has good weldability using suitable nickel-alloy procedures. Matching filler metals such as ERNiCrMo-17 may be used with clean joint surfaces, controlled interpass temperature and the required inspection.

Alloy C-2000 contains more chromium and a deliberate copper addition, extending performance in many oxidizing and sulfuric acid environments. Alloy C-276 contains tungsten and remains an established choice for many reducing and mixed chemical services. Selection should be based on actual process chemistry.

Please send the product form, dimensions, quantity, applicable ASTM or ASME standard, delivery condition, inspection requirements, destination and service temperature. Process chemistry, acid concentration and cleaning conditions should also be provided when corrosion suitability must be reviewed.
