Forgings Products

Inconel 600 Forgings

Inconel 600 Forgings are manufactured from a nickel-chromium alloy that provides excellent resistance to oxidation, corrosion, and high-temperature service conditions. The forging process produces dense, reliable components with consistent strength and dimensional stability under exposure to heat, steam, alkaline solutions, and other aggressive media.
Inconel 600 Forgings are widely used for valves, shafts, flanges, pressure components, and furnace hardware in chemical processing, heat treatment, nuclear power, aerospace, and energy applications. Their durability, resistance to stress corrosion cracking, and long service life make them a dependable choice for demanding industrial environments.







Request Quote View Specifications
Product Overview

Inconel 600 Forgings for High-Performance Applications

Explore detailed information for this alloy product, including specifications, applications, supply options and quotation requirements.

Why buyers choose Inconel 600 Forgings

Inconel 600 Forgings are manufactured from a nickel-chromium alloy that provides excellent resistance to oxidation, corrosion, and high-temperature service conditions. The forging process produces dense, reliable components with consistent strength and dimensional stability under exposure to heat, steam, alkaline solutions, and other aggressive media.
Inconel 600 Forgings are widely used for valves, shafts, flanges, pressure components, and furnace hardware in chemical processing, heat treatment, nuclear power, aerospace, and energy applications. Their durability, resistance to stress corrosion cracking, and long service life make them a dependable choice for demanding industrial environments.







Inconel 600 Forgings
Pipe Specifications

Inconel 600 Forgings size range and supply information

Specifications, available sizes and delivery conditions can vary by production route and order requirements. Contact us for current availability.

Item Typical Options Buyer Notes Typical Specification
Material Grade Inconel 600 / UNS N06600 / W.Nr. 2.4816 Confirm the alloy designation, chemical composition and certification requirements. Nickel-chromium alloy with good oxidation and high-temperature resistance
Forged Product Type Forged rings, discs, blocks, shafts, hubs, bars or custom components Provide the component type, geometry and finished-machining requirements. Open-die or closed-die forgings available
Dimensions Custom diameter, thickness, length or near-net-shape dimensions Submit drawings or dimensional details with machining allowances. Manufactured according to drawings or project specifications
Forging Process Open-die forging, closed-die forging, ring rolling or upset forging Select the process according to component size, shape and required grain flow. Controlled forging reduction for a uniform structure
Applicable Standard ASTM B564, ASME SB564, AMS 5665 or customer specification Confirm the required material, heat-treatment and dimensional standards. ASTM B564 / ASME SB564 / AMS 5665
Heat Treatment Solution annealed, annealed or custom heat-treatment cycle Match the heat treatment to strength, corrosion resistance and service temperature. Solution treatment with controlled cooling available
Machining & Surface As-forged, rough machined, finish machined, turned or ground Specify machining allowances, surface roughness and final tolerances. Precision machining available according to drawings
Inspection & Certification MTC, PMI, chemical analysis, tensile test, hardness test, UT, macro-etch testing and dimensional inspection Confirm testing scope, traceability and third-party inspection requirements. EN 10204 3.1 certificate and full heat traceability available







Standards

Common standards for Inconel 600 Forgings

The final standard should follow the purchase order, engineering specification or project drawing.

Product Type Common Standards Typical Use Inspection Notes
Inconel 600 Open-Die Forgings ASTM B564 / ASME SB564, AMS 5665 Large shafts, rings, pressure components and high-temperature industrial equipment Verify forging reduction, grain flow, dimensions, tensile properties, PMI and ultrasonic testing.
Inconel 600 Closed-Die Forgings ASTM B564 / ASME SB564, AMS 5665 Aerospace parts, valve bodies, pump components and complex heat-resistant assemblies Inspect die-fill quality, dimensional tolerances, surface condition, mechanical properties and traceability.
Inconel 600 Forged Rings ASTM B564 / ASME SB564, AMS 5665 Flanges, seals, pressure vessels, furnace components and reactor equipment Check ring dimensions, grain orientation, ultrasonic inspection, PMI, hardness and material certificates.
Inconel 600 Forged Bars ASTM B166 / ASME SB166, ASTM B564 / ASME SB564 Fasteners, shafts, valve stems and machined corrosion-resistant components Verify diameter, straightness, tensile properties, hardness, surface quality and heat traceability.
Inconel 600 Forged Flanges ASTM B564 / ASME SB564, ASME B16.5, ASME B16.47 High-temperature piping, nuclear systems, chemical plants and furnace service Inspect pressure class, facing, bolt-hole pattern, dimensions, PMI, NDT and forging soundness.
Custom Inconel 600 Forgings ASTM B564 / ASME SB564, AMS 5665, customer drawings Specialized aerospace, nuclear, power-generation and thermal-processing components Review drawings, heat treatment, grain flow, mechanical testing, NDT, PMI and inspection documentation.







Chemical Composition

Inconel 600 Forgings composition reference

Chemical composition is reported by heat on the material test certificate. Use the table below as a material-selection reference.

Element Symbol Typical Requirement Function
Nickel Ni 72.0 min Provides corrosion resistance, toughness, and resistance to chloride stress corrosion cracking.
Chromium Cr 14.0-17.0 Improves oxidation resistance and high-temperature forging performance.
Iron Fe 6.0-10.0 Provides alloy balance and contributes to forging strength.
Carbon C 0.15 max Controlled to maintain ductility, forgeability, and weldability.
Manganese Mn 1.0 max Acts as a deoxidizer during alloy production.
Silicon Si 0.50 max Controlled to maintain forging quality and mechanical properties.
Copper Cu 0.50 max Controlled minor element supporting alloy stability.
Cobalt Co 1.0 max Controlled residual element in the nickel-based alloy.
Sulfur S 0.015 max Controlled impurity to reduce brittleness and cracking during forging.







Mechanical Properties

Mechanical Properties of Inconel 600 Forgings

Mechanical properties vary by standard, pipe size, production route and heat treatment. Use the specified standard and MTC as the final acceptance basis.

Condition / Product Tensile Strength Yield Strength 0.2% Elongation Notes
Annealed Inconel 600 forgings 550 MPa min reference 240 MPa min reference 30% min reference Common reference condition for high-temperature, chemical-processing, and corrosion-resistant components.
Solution annealed Inconel 600 forgings By ASTM / ASME specification By ASTM / ASME specification By ASTM / ASME specification Provides improved metallurgical consistency, ductility, and resistance to oxidation.
Open-die Inconel 600 forgings By forging size, heat treatment, and specification By forging size, heat treatment, and specification By forging size, heat treatment, and specification Specify forging reduction, grain flow, dimensional tolerances, and inspection requirements.
Custom Inconel 600 forgings By design and purchase specification By design and purchase specification By design and purchase specification Confirm shape, weight, heat treatment, NDT requirements, surface condition, and material traceability.







Values shown are reference data for product selection. Purchase orders should define the exact standard, condition, inspection scope and certificate requirement.

Quotation Checklist

Information to confirm for your order

Share your requirements, including material, size, quantity, and specifications, for a fast quotation.

Material

Grade name, UNS number, equivalent grade or project material code.

Pipe Size

OD / NPS, wall thickness or schedule, length, tolerance and quantity.

Standard

ASTM, ASME, EN, DIN, drawing or customer specification.

Condition

Seamless, welded, annealed, solution annealed, pickled or polished.

Inspection

MTC EN10204 3.1, PMI, UT / ET, hydrotest and dimensional report.

Delivery

Destination, packing requirement, shipping method and delivery deadline.

Related Products

Related Products for Inconel 600 Forgings

Browse related alloy products and product forms that may suit the same application.

Related Articles

Articles about Inconel 600 Forgings standards, material selection and applications

View All
FAQ

Frequently asked questions about Inconel 600 Forgings

FAQ content helps cover buyer questions and supports SEO for long-tail product searches.

Inconel 600 Forgings are used for valves, flanges, shafts, pressure components, pump parts, furnace equipment, heat treatment systems, aerospace components and chemical processing applications.

Common standards include ASTM B564 and ASME SB564 for nickel alloy 600 forgings. Forged components can also be manufactured according to ASTM, ASME, AMS, API or customer specifications.

Available products include forged rings, discs, blocks, bars, shafts, flanges, valve bodies, hubs and custom near-net-shape forgings manufactured from customer drawings.

Yes. Inconel 600 Forgings can be supplied in solution-annealed or other specified heat-treated conditions, with mechanical properties and heat treatment records provided when required.

Yes. Forgings can be supplied with an EN10204 3.1 certificate, heat number traceability, chemical analysis, mechanical test results, PMI, dimensional inspection and ultrasonic testing when specified.

Please provide the forging type, material grade, dimensions or drawing, quantity, heat treatment condition, applicable standard, inspection requirements, certificate requirements and destination.

Request Inconel 600 Forgings Quote

Send your pipe size, standard and quantity

For faster feedback, include OD / NPS, wall thickness or schedule, length, quantity, standard, certificate requirement and destination. If you have a drawing or project specification, send it with the inquiry.
